GPHQ X cycloidal reductor with Several Tooth, High Strength, Credibility and Long Lifespan Made of Bearing Steel
1. Motor: Y2 or MS three phase motor , ML single phase motor
2. Type of input: Motor, flanged and shaft
3. Transmission stage: 1 and 2
4. Installment selection: Horizontal, vertical and flange of quadrate
5. Fit for clockwise and counter clockwise and compact volume
6. Ratio range: 9 to 5, 133
7. Power rage: 0.12-30kw
The features
1. Large transmission ratio, for single transmission ratio is 1/6-1/87, and for double is 1/99-1/7569
2. High transmission efficiency. The average efficiency is over 90%
3. Small volume, light weight
4. Low noise when operating, less fault, long life, stable and reliable operation, easy disassembly, easy repair.
5.Housing material:HT200 Cast iron
6.Cycloid wheel material:GCr15
7.Input/Output shaft material:#45 High-carbon chromium steel
8.Lubricating oil:GB 2# Lithium grease, Mobilux EP 2
9.Heat Treatment:Tempering,quenching
10.Efficiency:94%~96%
11.Noise (MAX):60~70dB
12.Temp. rise (MAX):60°C
13.Vibration:≤20µm
14.Backlash:≤60Arcmin
Product part information (because the file is too large, please contact us for details , thank you ^_^) :
